Suntech 510W N-Type TOPCon Glass-Glass MONOFACIAL Full Black Module
Suntech 510W N-Type TOPCon Glass-Glass MONOFACIAL Full Black Module
$155.00
$0.30 /Watt
Aesthetic appearance design
Elegant design in all-black appearance, harmonious integration with the components of the building to provide an intense aesthetic experience
Lightweight double glass
Lightweight double glass structure which effectively reduces the rate of module breakage. The ideal module size and weight make handling and installation easier
Withstand harsh environments
Reliable quality that makes module resistant even to high temperatures, salt water and ammonia
Superior load-bearing capability
Module certified to withstand 5400 Pa front side max static test load and 2400 Pa rear side max static test load.*
Download Datasheet Installation Manual Salt Mist CertificateWarranty
BrandSuntech
| Brand | Suntech |
|---|---|
| Panel Depth (mm) | 30 |
| Panel Width (mm) | 1134 |
| Panel Height (mm) | 1961 |
| Weight (kg) | 23.500000 |
| Max Power at STC (pMax) | 510W |
| Operating Voltage (Vmp) | 33.70V |
| Operating Current (Imp) | 15.13 |
| Open circuit voltage (Voc) | 40.54 |
| Short Circuit Current (Isc) | 15.95 |
| Cell type | N-Type Monocrystalline silicon |
| Module Frame | Anodized aluminium alloy |
| Efficiency | 22.9% |
| Connectors | Wuxi Suntech STP-XC4-4 (Default)/ Staubli PV-KST4-EVO2A/xy (Optional) |
| Brand | Suntech |
|---|---|
| Panel Depth (mm) | 30 |
| Panel Width (mm) | 1134 |
| Panel Height (mm) | 1961 |
| Weight (kg) | 23.500000 |
| Max Power at STC (pMax) | 510W |
| Operating Voltage (Vmp) | 33.70V |
| Operating Current (Imp) | 15.13 |
| Open circuit voltage (Voc) | 40.54 |
| Short Circuit Current (Isc) | 15.95 |
| Cell type | N-Type Monocrystalline silicon |
| Module Frame | Anodized aluminium alloy |
| Efficiency | 22.9% |
| Connectors | Wuxi Suntech STP-XC4-4 (Default)/ Staubli PV-KST4-EVO2A/xy (Optional) |
